Current Probe Electric Probe UL Wedge Probe

Large Image : Current Probe Electric Probe UL Wedge Probe

Product Details:

Place of Origin:	China
Brand Name:	Julixing
Certification:	ISO 17025 CNAS Test Report
Model Number:	LX-S113

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Contacts us
Packaging Details:	Standard packing
Delivery Time:	7~9 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500 Set per month

Contact Now

Detailed Product Description

Transportation:	DHL Express

Household and home/office document/media shredders

UL 60950 Wedge Probe for Paper Shredders

1. Specification:

Length: 300 mm

Bent finger diameter: 12 mm

Bendable Section: 30/30/40 mm

Baffle diameter: 50 mm

Baffle length: 100 mm

Material: Stainless steel

Reference: UL60950 Fig NAF.2 and NAF.3

2. Reference standard:

UL60950 Figure NAF2 and NAF3

3. Product Details:

This product is used for testing access to document shredders. The Jointed Accessibility Wedge Probe is a high precision probe made in exact accordance with UL and IEC standards such as UL60950 Figure NAF2 and NAF3 UL 60950 wedge probe for paper shredders.

The wedge probe is made of solid aluminum to conserve weight yet maintain rigidity. Others maintain that the tip needs to be more rigid, because of the cutting blades. The Shredder Accessibility Probe is intended for testing paper shredders in accordance with Annex NAF of the Standard for Information Technology Equipment.

Note: The thickness of the probe varies linearly, with slope changes at the following points along the probe.
