Basic introduction:
1. Accord with IEC60695-2-10, UL746A.
2. Using electricity heating regulation material (Ni80 / Cr20) of resistanse wire (Φ 4 mm Ni-Cr alloy wire) to 0°C~ 1000°C in 1 min,then with 1.0 N vertically burn it 30s,measure the fire risk by product light-off or holde burning time ,also test light-off degree, light-off temperature (GWIT), flammability and combustible index (GWFI).
3. Suitable for lighting equipment, low voltage electric appliance,electrician instruments and material flammability testing, such as electrical and electronic products.
Specifications:
| Model | LX-GW171 | LX-GW172 |
| Controller | Touch screen controller | Button controller |
| Glow wire | diameter 4mm±0.04mmNi/Cr(80/20), standard | |
| Temperature range | 500-1000°C ±2°C continus adjustable | |
| Thermocouple | diameter 0.5mm Type K (Ni/Cr - Ni/Al), armored sheath can withstand temperature -40~ 1100°C | |
| Searing Time | 30s±0.1s (OMRON H5CN-XAN-Z digital timer, 0-9999s, presettable) | |
| Light-off Time | 0-999.9 s ± 0.1 s, automatic recording, manual timeout | |
| Fireouttime | 0-999.9 s ± 0.1 s, automatic recording, manual timeout | |
| Ironing into depth | 7mm ± 0.5 mm | |
| Sample pressure | 1N ± 0.2 N | |
| Test speed | 18±3mm/s | |
| Test background | black background | |
| Test process | automatic control, independent convulsions | |
| Chamber | ≥0.5m | |
| Size | W1100mm×D700mm×H1300mm, exhaust hole Ø100mm can customize | |
| Control | Using single chip microcomputer + touch screen control | |
| Consult standard | IEC60695-2-10:2000,UL746A | |
| Power Supply | 800VA ,220V, 48-60Hz | |
