UL 746A Glow Wire Tester

: Large Image : UL 746A Glow Wire Tester

Product Details:

Place of Origin:	China
Brand Name:	Julixing

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Contacts us
Packaging Details:	Standard packing
Payment Terms:	T/T,Western Union,MoneyGram,AliExpress
Supply Ability:	500 Set per month

Contact Now

Detailed Product Description

Incoterms:	CFR	Transportation:	DHL Express
Product Style:	Lab Equipment

Specification:

Glow Wire Test Instrument is according to IEC60695-2-1, IEC60695-2-13 (GB/T5169.10-2006~GB/T5169.13-2006), and UL746A, IEC829, DIN695, VDE0471, the glow wire Test Instrument CX-Z17 is suitable for resistance to abnormal heat and fire test on lighting lamps, electronic products and household appliances. Adopting high-temperature coating spraying on steel structure and imported instrument display, with easy operation, stable performance the equipment is applicable to flame resistance tests of all levels of QC departments and cooresponding enterprises.

Technology Parameters:

Glow wire temperature: adjustable continuous within the range of 500~1000°c, the resolution of temperature is ±2°c
Glowing time: 0.1~999.9s, ±0.1s ( time range is adjustable)
Burning time: 0.1~999.9s, auto record and manual pause
Flame chilling time: 0.1~999.9s, auto record and manual pause
Glow wire pressure on test specimen: 1±0.2N. Limiting pressure depth is 7mm
Glow wire: diameter is 4mm include nickel (80%) and chromium (20%) which made in specific dimensions
Thermoelectric couple: φ0.5 armored nickel & chromium/ nidkel-chromium wire, K degree
Auto break away: While reaching specified glowing time, test specimen will break away from glow wire automatically
Working power supply: AC220V/50HZ and less than 500W
Equipment dimension: W1100mm x D700mm x H1300mm

Company introduction

Shenzhen Julixing Instruments Co., Ltd. are specialized in manufacturing special, custom built, test and measuring equipment for products testing as per international norms and offering calibration services and related information. Our products and services are used by research & development establishments, test laboratories, defense establishments, government institutions & manufacturing industries to fulfill the clients' requirements.

If you require equipment to test products such as home appliances, electrical accessories like switches, sockets, connectors, etc. industrial & road lighting luminaires, automobile lighting systems or related categories, we can provide the solutions you need.
