IRAM 2092, AS/NZS/EN/SASO/IEC 60335 Test Probe Kit

Meets IEC 60335. Accessibility probes are used to test the size of openings to ensure that fingers and objects do not have access to hazardous parts in equipment and machinery.

SPECIFICATIONS

1. Jointed Finger Probe: Precision probe which follows IEC specifications and meets the newest requirements. The design features a plan simulator to prevent misuse and a restricted joint movement which simulates human finger movement. This model meets CSA, IEC, UL and other industry requirements.

2. Test Pin Probe 15mm: A quality probe used to test for accessibility of small objects manufactured of rugged Delrin with a stainless steel tip, it is machined with precision to meet industry standards. Meets CSA, IEC, UL and other industry requirements.

3. Test Pin Probe 50mm: It is designed to perform tests in large and small scale products. The Test Pin Probe 50mm was design to attend your necessities of accessibility testing. The Test Pin Probe 50mm is used to test for accessibility of small objects and meets IEC, CSA, and UL requirements. Same as Test Pin Probe 15mm, except the metal tip is 50mm long. Tip is 4mm. Meet IEC 61032.

4. Unjointed Finger Probe: Identical to the Jointed Finger Probe except that is rigid. Used for forceful insertion where the flexibility of the Jointed Finger Probe would be a hindrance. The handle is designed with a screw tap for use with a force gauge. Meets CSA, IEC, UL and other industry.

5. Test Thorn Probe: It is designed to perform tests in large and small scale products. It was design to attend your necessities of accessibility testing. It is used for testing appliances according to IEC, CSA and UL Standards. It is used to verify protection from hazardous hot or glowing parts.
